Specification
Features and Specifications
General - P-touch
| AC adaptor | Yes |
|---|---|
| Alkaline batteries | 6 X AA (LR6) |
| Cutter type | Full, Auto |
| Database upload from PC | Yes |
| Housing colour | White and grey |
| Housing design | Desktop |
General Supplies
| Adapter type | AD-24 |
|---|
Dimensions & weights
| Dimensions | 66mm (W) X 188mm (D) X 112mm (H) |
|---|---|
| Weight without carton (includes toner & drum) | 0.6 kg |
In the box
| AC adaptor | Yes |
|---|---|
| AC adaptor power cord | Yes |
| Label design software | CD-ROM |
| Software | 1 |
| Software disc | P-Touch Editor 5.0 for Windows |
| Tape cassettes | 1 x 24mm black on white TZ tape (8 meters) |
| USB cable | Yes |
| User guide | Yes |
| Warranty card | Yes |
Operating systems & software
| Windows | Windows 2000, Windows Vista, Windows XP |
|---|
Label design
| Block format | Yes |
|---|---|
| Fonts | All installed True Type fonts |
| Frames | 126 |
| Line format | Yes |
| Tab setting | Yes |
| Text alignment | Centre, Justify, Left, Right |
P-touch Editor label design software
| Copies | 1 - 200 |
|---|---|
| Database file compatibility | csv, Microsoft Excel |
| Favourite object save/recall | Yes |
| Fonts | All installed True Type fonts |
| Frames | 126 |
| Label orientations | Horizontal, Vertical |
| Languages | English / French / German / Dutch / Italian / Spanish / Portuguese / Danish / Norwegian / Swedish |
| Screen capture | Yes |
| Sequential numbering | 1 - 5000 / A - Z / a - z |
| Tape size detection | Yes |
| Text alignment | Centre, Justify, Left, Right |
P-touch Editor Lite label design software
| Copies | 1 - 200 |
|---|---|
| Frames | 10 |
| Langauges | English / French / German / Dutch / Italian / Spanish / Portuguese / Danish / Norwegian / Swedish / Finnish / Czech / Hungarian / Polish |
| Screen capture | Yes |
| Tape size detection | Yes |
| Text alignment | Centre, Justified, Left, Right |
| Vertical print | Yes |
| Fonts | All installed True type fonts |
Supplies and accessories
| AC adaptor | AD-24 |
|---|---|
| Tape widths | 3.5, 6, 9, 12, 18, 24mm TZ Tape |
Warranty
| Warranty | 3 year back to base warranty (upon registration) |
|---|
