Specification
Features and Specifications
General - P-touch
| AC adaptor | Yes |
|---|---|
| Machine type | PC connectable |
| Maximum tape width (mm) | 36 |
| Usage type | Industrial |
| Buttons | Power, Feed, Cut |
| Cutter type | Full and half, Auto |
| Flash RAM | 2 MB |
| Housing colour | Light grey % pearl white |
| Housing design | Desktop |
| Image upload from PC | Yes |
| LED | Status |
| Template upload from PC | Yes |
| Unit setting (mm / inches) | Yes |
General Supplies
| Width | TZ tape: 3.5, 6, 9, 12, 18, 24, 36 mm - HG tape: 12, 24, 36 mm |
|---|---|
| Type | TZ and HG tape |
| Adapter type | AD-9100ES 100-220 auto switching AC adapter |
Connectivity
| USB interface | ver 2.0 full sped |
|---|
Dimensions & weights
| Dimensions | 116mm (W) x 193mm (D) x 140mm (H) |
|---|---|
| Weight without carton (includes toner & drum) | 1.57 kg |
In the box
| AC adaptor | Yes |
|---|---|
| AC adaptor power cord | Yes |
| Label design software | CD-ROM |
| Software | 1 |
| Software disc | P-Touch editor |
| Tape cassettes | 36 mm HG-261 black on white label cassette (8mm) |
| USB cable | Yes |
| User guide | Yes |
| Warranty card | Yes |
Operating systems & software
| Windows | Windows 7, Windows 8, Windows Vista, Windows XP |
|---|
Label design
| Block format | Yes |
|---|---|
| Download contents from Brother cloud | via P-Touch editor |
| Line format | Yes |
| Rotate text | Yes |
| Tab setting | Yes |
| Text alignment | Centre, Justify, Left, Right |
| Text widths | 2x, Normal |
| Underline | Yes |
| Vertical printing | Yes |
Label design software
| Database file compatibility | csv, Microsoft Access, Microsoft Excel |
|---|---|
| Date and time stamp | Date and time |
| Image format support | DIB, GIF, ICO, JPG, PNG, TIFF, WMF |
| Label orientations | Horizontal, Vertical |
| Microsoft Office add-in (highlight->click->print) | Excel, Outlook, Word |
| Sequential numbering | 1 - 5000, A - Z, a - z |
| Table | Yes |
| Tape size detection | Yes |
| Text alignment | Centre, Justified, Left, Right |
| Typestyles | Bold, Italic, Normal, Shadow |
| Vertical print | Yes |
Supplies and accessories
| AC adaptor | AD-9100ES 100-220 auto switching AC adaptor |
|---|---|
| Tape widths | TZ tape: 3.5, 6, 9, 12, 18, 24, 36 mm - HG tape: 6, 12, 24, 36 mm |
Warranty
| Warranty | 3 year back to base warranty (upon registration) |
|---|
