Print high-quality, continuous labels using media up to 118mm/4.65 inch wide.
| Maximum label width (mm) | 102 |
|---|---|
| Usage type | Industrial |
| Buttons | Power, Feed |
| Database upload from PC | Yes |
| Flash RAM | 40 MB |
| RAM | 256 MB |
| Technology | Direct thermal |
| Serial | RS232C Original serial cable |
|---|---|
| USB interface | USB Ver. 2.0 (Full Speed) (Type B) |
| Dimensions | 180 mm (W) x 224 mm (D) x 155 mm (H) |
|---|---|
| Weight without carton (includes toner & drum) | 2.08 kg |
| AC adaptor | Yes |
|---|---|
| Quick setup guide | Yes |
| Windows | Windows 10, Windows 8, Windows 7, Windows Server 2003 & 2008 (32 & 64 bits), Windows Vista, Windows XP |
|---|
| 1 dimensional barcode symbologies | Linear: CODE 39, ITF(I-2/5), EAN-8(JAN8), EAN-13(JAN13), UPC-A, UPC-E, CODABAR (NW-7), CODE 128, GS1-128(UCC/EAN 128), GS1 Databar (Standard (Omnidirectional)/Truncated/Stacked/Stacked Omnidirectional/Limited/Expanded), CODE93, POSTNET, UPC/EAN EXTENSION, MSI, Intelligent Mail Barcode |
|---|---|
| Maximum print length | 3000 mm |
| Maximum print width | 104.1 mm |
| Resolution (dpi) | 203 |
| Standard print speed | 203.2 mm per second |
| Supported commands | Raster ESC/P P-touch Template ZPL emulation CPCL emulation(CPCL page print mode / CPCL line print mode) SBPL emulation (JP model only) |
| SDK (Software Development Kit) | Yes |
|---|
| Warranty | 2 Year Return to Base Warranty |
|---|
Routine maintenance to keep your printer performing at its best.
We recommend cleaning your printer on a regular basis to maintain its correct performance. Always disconnect the printer from any power source before cleaning.
Clean the exterior of the unit.
Wipe any dust and marks from the main unit using a soft, dry cloth. Use a cloth slightly damp with water on difficult to remove marks. Important - do not use paint thinner, benzene, alcohol or any other organic solvent. These may deform or damage the printer case.
Clean the label output slot.
|
|
If adhesive residue gets attached to the label output slot, it may cause label jams. Clean the label output slot with a dry cotton swab.
Important – do not use alcohol to clean the label output slot.
Always remove the ejected labels from the label output slot. If the slot becomes blocked, label jams may occur. |
Clean the roller.
|
|
Wipe the roller with a lint-free cloth dipped in isopropyl alcohol or ethanol. After cleaning the roller, make sure that no lint or other material remains on the roller.
Use isopropyl alcohol or ethanol according to the manufacturer’s safety guidelines, as applicable. |
Clean the print head.
|
|
Wipe the print head with a lint-free cloth or cotton swab dipped in isopropyl alcohol or ethanol. We recommend cleaning the print head monthly.
Use isopropyl alcohol or ethanol according to the manufacturer’s safety guidelines, as applicable. |
