Specification Details
Features and Specifications
General
| Printer type | Mono |
|---|---|
| Function | Print, Copy and Scan, Fax |
| Display | LCD |
| Display size | 16 characters x 2 line LCD |
| Laser classification | Class 1 Laser Product (IEC60825 - 1:2007) |
| Max paper size | A4 |
| Memory | 32MB |
| Technology | Laser |
Connectivity
| Connectivity | Wireless |
|---|---|
| Local interface | Hi-Speed USB 2.0 |
| Wired network interface | IEEE 802.11b/g/n |
Mobile connectivity
| Supported | iPrint&Scan |
|---|
Copying
| Resolution | Up to 600 x 600dpi |
|---|---|
| Speed | Up to 20cpm (copies per minute) |
Dimensions & weights
| Dimensions with carton | 481 (W) x 436 (D) x 425 (H) mm / 10.1kg |
|---|---|
| Dimensions without carton | 385 (W) x 340 (D) x 283 (H) mm / 8.2kg |
Environmental
| Sound power | 6.6BA active, 4.7BA ready |
|---|---|
| Sound pressure | 52dBA active, 32dBA ready |
Faxing
| Fax modem | 14.4 kbps |
|---|---|
| PC Fax | Send and Receive |
In the box
| Contents | Power supply cord, Fax line cord, Product safety guide, Software disc, Supplies, User guide, Warranty card, Quick setup guide |
|---|
Media specifications
| Types and sizes | Standard Tray - A4, Letter, Legal, Folio, A5 ,A5(Long Edge), B5, Executive, ADF (Automatic Document Feeder) - A4, Letter, Legal, Folio |
|---|---|
| Weights | Standard Tray - Plain & recycled paper (between 65 - 105 g/m2), ADF (Automatic Document Feeder) - Plain & recycled paper (between 65 - 90 g/m2) |
Network
| Wireless network | IEEE 802.11b/g/n (Infrastructure Mode/Ad-hoc Mode) |
|---|---|
| Wireless network security | WEP 64/128, WPA-PSK (TKIP/AES), WPA2-PSK (AES), SMTP-AUTHWEP 64/128, WPA-PSK (TKIP/AES), WPA2-PSK (AES), SMTP-AUTH |
| Wireless setup support | Yes |
Operating systems & software
| Supported | Windows® 8(32 & 64 bit editions), Windows® 7 (32 & 64 bit editions), Windows Vista® (32 & 64 bit editions), Windows® XP Professional (32 & 64 bit editions), Windows® XP Home Edition, Windows® Server 2012R2, Windows® Server 2012, Windows® Server 2008R2, Windows® Server 2008 (32 & 64 bit editions), Windows® Server 2003 (32 & 64 bit editions). Note that Windows® Server supports network printing only. OS X 10.6.8, 10.7.5, 10.8.x, 10.9.x, 10.10.x or greater. Linux CUPS, LPD/LPRng (x86/x64 environment) |
|---|
Paper handling
| Paper input | 150 Sheet Paper Tray, 10 Sheet ADF |
|---|---|
| Paper output | 50 Sheets (face down) |
Printing
| A4 standard print speed | Up to 20 pages per minute |
|---|---|
| Resolution | Up to HQ1200 (2400 x 600dpi) |
| Emulations | GDI (host based) |
| First print out time | Less than 10 seconds |
Scanning
| Resolution | Up to 600 x 1,200dpi (from scanner glass), Up to 600 x 600dpi (from ADF), Up to 19,200 x 19,200dpi (interpolated) |
|---|---|
| Scan to | Email, Image or File |
| Scanner type | CIS |
Solutions
| Supported | iPrint&Scan |
|---|
Supplies and accessories
| Supplies | Inbox Toner - 700 pages*, Standard Toner (TN-1050) - 1,000 pages*, Drum (DR-1050) - 10,000 A4 Pages *Approx. cartridge yield is declared in accordance with ISO/IEC 19752 |
|---|
