The feature-packed compact scanner for the small office
From the easy-to-use 6.9cm colour touchscreen to the 18ppm scan speed, the ADS-1600W is all set up to meet your modern office needs. Features wireless network connectivity built in, as well as fast double-sided scanning in a single pass up to 1,200 dpi print resolution.
Compact business scanner with wireless, 2-sided scanning and touch Screen. Work direct from the scanner enabling users to quickly navigate scan functions with the intuitive touch screen. Easy to transport across departments for cross function usage.
With the Brother scanners, legal firms can significantly cut down their admin time dealing with the thousands of documents they need to collect, store and share.
Finance and insurance companies have an increasing need for paperless document management whether for compliance, internal collaboration or customer requirements. Scanning helps reduces the time and effort in long term storage and management of contracts. Brother scanners help bridge the gap between paper processes and effective digitisation.
| Usage type | Desktop |
|---|---|
| Display | Backlit LCD |
| Display size | 6.8cm |
| Multi feed sensor | Yes |
| RAM | 256 MB |
| USB interface | High Speed USB 2.0 |
|---|---|
| Wireless network interface | Yes |
| Dimensions with carton | 380 W x 170 D x 207 H mm |
|---|---|
| With carton | 2600 g |
| Dimensions without carton | 285 W x 103 D x 84 H mm |
| Weight | 1600 |
| Printing | 14 watts |
|---|---|
| Ready mode | 4 watts |
| Sleep mode | 1.5 watts |
| Off | 0.25 watts |
| Sound power | 59 dB |
| Sound pressure | 47 dBA |
| Operating humidity | 20 - 80% |
|---|---|
| Operating temperature | 5 - 35°C |
| AC adaptor | Yes |
|---|---|
| Power supply cord | Yes |
| Product safety guide | Yes |
| Software disc | Driver software for Windows® and Mac OS |
| USB cable | Yes |
| User guide | Yes |
| Quick setup guide | Yes |
| Types and sizes | Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Business Card, Plastic Card |
|---|---|
| Weights | 52 - 110 gsm (multiple sheets) |
| ADF media sizes | Paper (multiple sheets): 51-215.9x70-297mm, Paper (single sheet): 51-215.9x70x863mm, Plastic card: 51-55x70-95mm, Plastic card Thickness: 0.4-0.76mm |
| IPv4 | Yes |
|---|---|
| Network protocols | ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, Custom Raw Port/Port9100, FTP Client and Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Scan), SNTP Client |
| Wireless network | Built‐in 802.11b/g/n wireless network |
| Wireless network security | APOP, POP before SMTP, SMTP-AUTH, SSL/TLS (HTTPS, SMTP), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES). |
| Wireless setup support | Yes |
| 2-Sided scan | Yes |
|---|---|
| ADF | 20 |
| Scan to | email, Image, OCR, File, email server, USB, Network, Cloud |
| Colour A4 scan speed | 18 ppm |
| Colour depth | 30/24 bit |
| Greyscale | 256 levels |
| ICA compatibility | Yes |
| Interpolated scan resolution | 1200 x 1200 dpi |
| ISIS compatibility | Yes |
| Multi feed detection | Yes |
| Paper sensor | Yes |
| SANE compatibility | Yes |
| Scan resolution from ADF | 600 x 600 |
| TWAIN compatibility | Windows 7, Windows 8, Windows Vista, Windows XP |
| WIA compatibility | Yes |
